Battery Specification
Model: BJ48-240
Type of Cell: LiFePO4 (Square steel shell)
Rated voltage: 51.2V
Standard capacity: 240Ah
Charging voltage: 57.6V-60V
Cut-off: 2.5V single cell
Self-Discharge( 25℃): ＜3％/month
Depth of discharge: Up to 95％
Charge method ( CC/CV ): Operation： -20℃—70℃; Recommendation: 10℃—45℃
Warranty: 5years
Size : 1136*540*190mm
Float charge voltage/V
Weight: 134.6KG
Electrical Characteristics: 55.2
Max. continue discharge current/A: 100
Max. continue chargecurrent/A:
Max. pulse discharge current/A: 150A 1Sec.
100
Operating conditions
Cycle life (+25℃ 0.2C 100%DOD): >6000 Cycles
Storage temperature: 0 to 30℃
Storage duration: 6 months at 25℃
Safety standard: UN38.3,IEC62619,CE
